2023 KTM 250 XC-W
2023 KTM 250 XC-W
2023 KTM 250 XC-W
2023 KTM 250 XC-W
2023 KTM 250 XC-W
2023 KTM 250 XC-W
2023 KTM 250 XC-W
2023 KTM 250 XC-W
2023 KTM 250 XC-W
2023 KTM 250 XC-W

2023 KTM 250 XC-W

Regular price $0.00 Save $0.00
/

Only 0 items in stock!

The KTM 250 XC-W is the ultimate combination of power and rideability and sets a clear benchmark for intuitive handling, unique style and top performance. Thanks to its groundbreaking TPI (Transfer Port Injection) technology, this extreme machine continues to reach new heights, clearly demonstrating KTM's unrelenting commitment to 2-stroke development. Besides the renowned benefits of excellent fuel efficiency, clean exhaust emissions and the eliminated need for jetting, the KTM 250 XC-W features a dynamic, lightweight frame. It was developed with feedback from factory riders and in hindsight, returns the favor by offering excellent rider feedback.



2023 KTM 250 XC-W Highlights

  • NEW graphic design and white, purple and orange color scheme come together to pay homage to the early ‘90s enduro models. An orange frame sets the graphics off and echoes KTM factory machines.
  • NEW Dunlop MX33 front tire pairs perfectly with the Dunlop AT81 rear for offroad domination.
  • WP XPLOR forks provide next-level control and comfort and are fully adjustable for terrain and rider preference.
  • WP XPLOR rear shock with PDS (Progressive Damping System) technology offers lower maintenance with fewer moving parts and provides more ground clearance.
  • Super lightweight Galfer Wave rotors, CNC machined hubs and high-end Giant rims provide excellent performance while reducing unsprung weight.
  • 249 cc 2-stroke engine with a 6-speed wide ratio transmission is fitted with a patented TPI fuel injection system for perfect fueling at any altitude, no premixing and reduced fuel consumption while still living up to the standard of a KTM 2-stroke.
  • EMS featuring an ECU controlling ignition timing and fuel spray based on information from sensors reading intake air pressure, throttle position, water temperature and ambient air pressure from an additional sensor for efficient altitude compensation.
  • Optional map select switch allows the rider to select an alternate map, providing a sportier power delivery.
  • Electronic oil pump feeds oil from the 700 cc oil tank to the intake to ensure a perfect fuel-oil mix under any condition while reducing smoking by 50% and providing up to 5 tanks of fuel.
  • Exhaust system provides improved performance with reduced weight and a more durable construction thanks to the innovative corrugated surface on the expansion chamber.
  • High-tech, lightweight chrome-moly steel frame with carefully calculated flex parameters provides a great blend of comfort, stability and precision.
  • Single-piece cast aluminum swingarm is manufactured using a gravity die-cast production process, offering exceptional strength at the lowest possible weight.
  • Hydraulic Brembo clutch system offers highly controllable modulation of the clutch and light operation, minimizing fatigue on demanding rides.
  • High-tech Brembo brakes have always been standard equipment on KTM offroad machines and are combined with lightweight Wave discs to offer incredible braking power and feel.

SPECIFICATIONS:

Engine Type: Single Cylinder, 2-Stroke

Displacement: 249 cc

Bore/Stroke: 66.4 / 72 mm

Starter: Electric, Lithium Ion 12 V 2 Ah

Transmission: 6 Gears, Wide Ratio

Fuel System: TPI, Dell’Orto 39 mm Throttle Body

Lubrication: Electronically Regulated Oil Pump

Primary Ratio: 26:73

Final Drive: 13:52

Cooling: Liquid Cooling

Clutch: Wet Multi-Disc DDS Clutch, Brembo Hydraulics

Ignition: Continental EMS

Frame: Central Double-Cradle Type 25CrMo4 Steel

Subframe: Aluminum

Handlebar: NEKEN, Aluminum Ø 28/22 mm

Front Suspension: WP XPLOR USD Ø 48 mm

Rear Suspension: WP XPLOR Shock with PDS

Suspension Travel Front/Rear: 300 mm / 11.8 in; 310 mm / 12.2 in

Front/Rear Brakes: Disc Brake 260 mm; 220 mm

Front/Rear Rims: 1.60 x 21” / 2.15 x 18” Giant

Front/Rear Tires: 80/100-21” Dunlop MX33 / 110/100-18” Dunlop AT81

Chain: 5/8 x 1/4 in

Silencer: Aluminum

Steering Head Angle: 26.5º

Triple Clamp Offset: 22 mm

Wheelbase: 1,482 mm ± 10 mm / 58.3 ± 0.4 in

Ground Clearance: 370 mm / 14.6 in

Seat Height: 960 mm / 37.8 in

Tank Capacity, Approx: 9 l / 2.4 gal

Weight (without fuel), Approx: 103.4 kg / 227.9 lbs
